What is a Through type quenching furnace? Introduction to the advantages and characteristics of heating furnace functions

Through type quenching furnaceIt is a kind of heating equipment using natural gas as fuel, which is mainly used to heat metal materials to the required forging temperature in a short time.，It can be used for Metal heat treatment, Improve production efficiency, Metal forging heating, Energy conservation and environmental protection, Metal melting and casting, Metal melting and casting and so on，the advantage is Using regenerative combustion system or advanced burner design can realize the uniform distribution of temperature in the furnace, ensure the uniform heating of metal materials and improve product quality.、Adopting advanced combustion technology and control system can realize full combustion of natural gas and improve combustion efficiency. At the same time, some equipment is also equipped with waste heat recovery system, which can further recycle the waste heat in exhaust smoke and improve energy utilization efficiency.、It can improve the plasticity and fluidity of metal materials, reduce the difficulty and cost of forging, and improve product quality and production efficiency.、Natural gas is mainly used as fuel, but some equipment also supports other types of gas or liquid fuel, which has strong fuel adaptability.、The user interface is friendly, and the operator is easy to use. At the same time, the equipment also has the function of fault diagnosis and alarm, which can find and deal with abnormal situations in time.，it has the characteristics of Easy to control, Easy to maintain, Strong adaptability, energy-efficient and energy saving and environmental protection，it is an ideal choice for customers to buy Through type quenching furnace。

1、Brief introduction of Through type quenching furnace

Through type quenching furnaceIt is a kind of equipment which uses gas as fuel and is specially used for heating metal before forging.，at work,The high-temperature flame and flue gas generated by burning gas (such as natural gas and liquefied petroleum gas) in the furnace are used as heat sources to heat metal materials.，the product looks atmospheric.，modern technology，low in price。

Through type quenching furnace

2、Structural characteristics of Through type quenching furnace

The Through type quenching furnace structure is introduced as follows:

1. ventilation system

Ensure the gas flow in the furnace and maintain the stability of the atmosphere and temperature in the furnace.

2. Radiation chamber

The heat load of the main place for Through type quenching furnace heat exchange accounts for about 70%-80% of the whole furnace. The furnace tube in the radiation room conducts heat through flame or high-temperature flue gas, which is mainly radiant heat, so it is called radiation tube.

3. Waste heat recovery system

Used to recover the exhaust heat of the heating furnace. There are two kinds of recovery methods, one is to recover by preheating combustion air, so that the recovered heat can return to the furnace again; The other is to use another recovery system to recover heat. The former is called air preheating mode, and the latter is usually called waste heat boiler mode.

4. ventilation system

Ensure the gas flow in the furnace and maintain the stability of the atmosphere and temperature in the furnace.

5. combustor

The device that mixes natural gas with combustion-supporting air and ejects it is the core component of the heating furnace.

Through type quenching furnace

3、Video analysis of Through type quenching furnace

On-site aerial photography of Through type quenching furnace。

Through type quenching furnace

As you can see from the live video.，One-combustion energy saving It is a kind of equipment that uses natural gas as fuel to heat metal materials and make them reach forging temperature.。

4、Through type quenching furnace characteristics

The Through type quenching furnace features are as follows:

1. Easy to control

The combustion system and ventilation system of the Through type quenching furnace can be adjusted as required to accurately control the temperature and atmosphere in the furnace and meet the heating requirements of different metal materials.

2. Easy to maintain

The structural design of the Through type quenching furnace is reasonable and easy to maintain, which reduces the operating cost and failure rate of the equipment.

3. Strong adaptability

The Through type quenching furnace can be used for forging and heating of bar, round steel, square steel, steel plate and other metal materials, and has a wide range of applications.

4. Easy to control

The combustion system and ventilation system of the Through type quenching furnace can be adjusted as required to accurately control the temperature and atmosphere in the furnace and meet the heating requirements of different metal materials.

5. Stable and reliable

The Through type quenching furnace has a stable combustion system and temperature control system, which can ensure the uniformity and stability of the temperature in the furnace, thus improving the quality and production efficiency of forged products.

Through type quenching furnace

5、Through type quenching furnace application

Through type quenching furnaces have the following purposes.

1. Improve production efficiency

The Through type quenching furnace has the advantages of fast heating speed and accurate temperature control, which can improve production efficiency. This is especially important for mass-produced forging workshops.

2. Metal melting and casting

Although it is mainly used for forging heating, some types of Through type quenching furnaces can also be used in metal melting and casting processes. This is especially suitable for melting and casting of small or special alloys.

3. Energy conservation and environmental protection

The Through type quenching furnace uses clean energy as fuel, which has lower emissions and higher energy efficiency than traditional coal-fired or oil-fired stoves. This is helpful to reduce environmental pollution and realize green production.

4. Metal tempering

By properly heating and cooling the metal material, the Through type quenching furnace can realize the quenching and tempering treatment of the metal. This is helpful to adjust the hardness and toughness of metal to meet the needs of different workpieces.

5. Metal heat treatment

In addition to forging heating, Through type quenching furnaces can also be used for metal heat treatment processes, such as annealing and tempering. These processes can improve the microstructure and properties of metal materials, and improve their service life and mechanical properties.

Through type quenching furnace

Through type quenching furnacethe product looks beautiful.，Widely used inMetal tempering,Improve production efficiency,Metal forging heating,Energy conservation and environmental protection,Metal heat treatment and so on。
