Introduction to Lock gas feeder, introduction to Feeder function advantages and characteristics

Lock gas feederis widely used in powder engineering, pneumatic conveying and dust removal system.，it is widely used inbuilding materials cement,metallurgy,energy mining industry,dock,grain processing and other industries，The motor reducer drives the impeller to rotate in the cylindrical casing. Materials fall from the upper hopper and are filled in the spaces between the impellers. With the rotation of the impellers, the materials are transported to the lower part and discharged. At the same time, the exhaust port exhausts the high-pressure gas generated by the rotation of the impeller, which reduces the phenomenon of gas ejection and ensures the continuity and stability of material transportation.。The following is to introduce the Lock gas feeder:

1、Brief introduction of Lock gas feeder

Lock gas feederis a device for discharging materials, which discharges materials from containers by specific mechanical or pneumatic means.，is an advanced Lock gas feeder developed by our company in combination with the actual situation of the industry。

Lock gas feeder

2、Working principle of Lock gas feeder

Lock gas feederat work,Based on a rotor with several blades rotating in a cylindrical casing. When the rotor rotates, materials fall from the upper hopper and are filled in the spaces between the blades. With the rotation of the impeller, the material is conveyed to the lower part and discharged. At the same time, the pressure equalizing exhaust port on the side of the machine body can exhaust the high-pressure gas generated by the rotation of the impeller, so as to reduce the phenomenon of gas ejection and ensure the smooth falling of materials.。

Lock gas feeder

3、Introduction of Lock gas feeder characteristics

Lock gas feederfeatures include flexible adjustment, easy maintenance, strong reliability, handsome appearance and compact structure，the main structure includes impeller, motor and transmission device, sealing element, main valve (including shell, end cover, impeller, sealing structure, etc.), rotor and shell and so on，Lock gas feederThe overall structural design is relatively simple。

Lock gas feeder

4、Lock gas feeder application

Lock gas feederIt has the functions of prevent gas or dust leakage, dust removal equipment discharges dust., dust removal equipment discharges dust., blowing-in and equipment feeding，The overall structural design is simple, diverse and beautiful.，structure mainly includes: impeller, sealing element, motor and transmission device, equalizing exhaust port, motor reducing gear and so on，can be customized according to user's needs.。

Lock gas feeder

5、Lock gas feeder structure

The Lock gas feeder structure is introduced as follows:

1. sealing element

Seals are used to ensure the sealing performance of the Lock gas feeder in the working process and prevent material leakage and gas backflow. High-quality seals can improve the working efficiency and service life of equipment.

2. Rotor and shell

The rotor is the core component of the Lock gas feeder, and usually consists of several blades, which rotate in the cylindrical casing. Materials fall from the upper hopper and are filled in the spaces between the blades. With the rotation of the impeller, they are transported to the lower part and discharged from the shell to protect the internal mechanism and seal, and prevent the leakage of materials and the entry of external impurities.

3. impeller

Impeller is the key part of the Lock gas feeder to realize material transportation. Its structural design is reasonable, which can ensure the uniform distribution of materials in the spaces between the impellers and be transported smoothly with the rotation of the impellers.

4. Motor and transmission device

The motor provides power for the Lock gas feeder, and the power is transmitted to the impeller through transmission devices (such as gears and sprockets) to make it rotate. The transmission device shall be designed to ensure smooth and reliable power transmission.

5. Equalizing exhaust port

The side of the Lock gas feeder body is provided with a pressure equalizing exhaust port, which can exhaust the high-pressure gas brought by the rotation of the impeller, reduce the phenomenon of gas ejection, and facilitate the smooth falling of materials.

Lock gas feeder

6、Lock gas feeder use

Lock gas feederWidely used in prevent gas or dust leakage, continuously and uniformly feed or discharge., ensure air tightness of the system, material handling and dust removal equipment discharges dust.。

Lock gas feeder

Lock gas feederMainly used forcontinuously and uniformly feed or discharge.,ensure air tightness of the system,prevent gas or dust leakage,material handling andequipment feeding，is the main equipment for dust removal equipment, ash discharge, air supply and other equipment feeding.。
